Jan Morel Signature line.



The Bow range is a new design born of the collaboration between Jan Morel and Artnovion.
The bow is an elegant balance between simplicity and futuristic design. The Bow is available in 3 different sizes.
Each Bow has a solid wooden shell, forming a carefully calibrated semi-circular diffuser, with dual lateral closed cavities packed with high-performance acoustic foam. The Bow has a further central Helmholtz cavity extending the mid-range frequency absorption, for an overall balanced mid-high frequency hybrid absorber with an outstanding geometric diffusion.



For color customisation please visit:

Bow Hybrid Absorber-Diffuser



Why use diffusion?
Diffuser panels scattering incoming sound waves into smaller, lower energy waves, scattered over a large area. These scattered reflections create a homogeneous sound field distribution and a full, balanced acoustic response. This improves speech intelligibility, music quality, and creates a more uniform, larger sweet spot.

Bow Hybrid Absorber-Diffuser - Range

  • Features:

    Units per box: 5



    Type:
    Hybrid Absorber



    Absorption range:

    160Hz to 4000Hz



    Acoustic Class:
    D | (αw) = 0,5



    Purpose:

    Mid-High absorption and diffusion


    Recommended for:
    Studios | Recording rooms

    Available in 3 sizes, all crafted from premium fabrics and quality wood, filled with high-performance acoustic foam.

    Combining the 3 different sizes of Bow creates distinct, unique designs and diffusion patterns.

    The Bow can be installed on walls or ceilings, hung on screws by means of a discreet imbedded backboard. It can also be installed directly through the front of the panel, concealed behind removable side-foam.

    Available in a selection of 10 wood and 10 fabric finishes.


    Available fire rates:
    FG | Furniture Grade

    Dimensions:
    Bow - S | 595x148x75mm
    Bow - M | 892x148x107mm
    Bow - L | 1190x148x138mm



    Integrated Fixing System alrready incorporated on the panel
